450 - DucTester System

European Commercial DucTester

Request a Quote
In stock
SKU
450

European Commercial DuctTester

9 kg Commercial Duct Tester is a Game Changer

Test to 250, 1000 or even 5000 Pa! Sufficient flow for almost every test. 600 square meters of duct or more can be tested.

Change the test direction by moving the 100 mm flex from the outlet to the inlet adapter which snaps on in one second. No clumsy flanges to disassemble.

Results in any desirable unit such as cubic meters per second per square feet is read directly off the gauge. Or, use the test to complete and automated test then have the software generate an EN12237, FE E51-767 or DW/143 compliant report that can be easily customized with your format, logos and even pictures of the test. Users love the set up and test speed.

One tech can take this tester to the jobsite by taxi or train. An industry first as is the ISO 17025 accredited calibration.

Who uses it?

  • Energy Auditors, HVAC Contractors, Building Contractors & Remodelers, Home Inspectors
1 x DM32 (20A) Digital Gauge Package
  • DM32 (20A) WiFi Dual Channel Color Touchscreen Manometer
  • USB Cable, 6' (1.8 m)
  • Cat5 Cable, 7' (2 m) Blue
  • DM32 USB Charging Module (120V/60Hz, 240V/50Hz, or 110V/50Hz)
  • DM32 Software Suite (Virtual Gauge, DM32 Configurator, Data Logger, and DM32 USB driver)
  • Gauge Case
  • DM32 Magnetic Clip
  • NIST Traceable Calibration
  • Gauge Calibration Verification Certificate
1 x 400 Series Fan Set
  • 400 Series Fan
  • DC Power Supply for 400 Series Fan
  • 400 Series Fan Power Cord With Plug Style for your country
  • Control Panel for 400 Series Fan
  • End Plate 300 - Range 102
  • Single Point Verification of Fan
  • System Calibration Report
1 x 441/451 DucTester Set of Range Plugs
  • 4" Plug - Range 74
  • 4" Plug - Range 47
  • 4" Plug - Range 29
  • 4" Plug - Range 18
1 x 451 Commercial DucTester Accessory Kit
  • Deluxe Tool Case
  • 10" to 4" reducer
  • 12 Ft long (4 m) 4" Flex Duct with 2.5" Collar
  • 4" (100 mm.) Duct Connection Flange
  • 8" x 8" (200 x 200 mm.) Duct Connecting Plate
1 x DucTester Tubing Kit
1 x Umbilical for DucTester, 7 ft (2 m)
Fan Model #: 400


Flow Into Back Pressure of:

CFM

litres/sec

m3/s

Maximum Flow at 120 or 230 VAC:

1 in WC (250 Pa)

306

144

0.144

4 in WC (1000 Pa)

302

143

0.143

8 in WC (2000 Pa)

295

140

0.14

Minimum Flow with std Range 18:

1 in WC (250 Pa)

7.1

12

0.00333

Minimum Flow (with opt Range 3):

0.31

0..52

0.00014

Dimensions:

14" × 14" × 26" (35 x 35 x 66 cm)

Weight of System:

18.4 lb (8.7 kg)

Flow Accuracy:

+/-5%

Power input:

120 V AC, 15.5 A, 50/60 Hz, 1 phase or
240 V AC, 8.5 A, 50/60 Hz 1 phase

Recommended Fan Calibration Interval:

5 years

Digital Gauge Model:

DM32 20

Special Features:

This special DM32 for the DucTester 450 has a 20 in. WC (5000 Pa) sensor.

Link to Specifications:

Click here to see the full specs for the DM32

* The max flow of the fan will vary depending on the following factors:
      barometric pressure, back pressure, blade pitch, air temperature, bearing tightness, inlet air turbulence, length of flex duct
